5-in-1ドッキングステーション

説明文
- Steam Deck および ROG Ally 用の 5 in 1 ドッキング ステーション: 4K@60Hz HDMI 出力、100 Mbps RJ45/イーサネット入力、USB-C 充電、およびデュアル USB-A 2.0 ポートを備えています。
- 強化されたビジュアル:外部 4K モニターに接続すると、4K@60Hz HDMI 2.0 出力でより鮮明でスムーズなビジュアルを楽しめます。
- フルスピード Steam Deck 充電:最大 100W の電力供給をサポートし、オリジナルの充電器を使用すると Steam Deck がフルスピードで充電されます。
- オールインワンの利便性:ハブとスタンドが一体化しているため、別途アクセサリを用意する必要がありません。セットアップが合理化され、ゲーミングエリアを整理整頓できます。
- 互換性: Steam Deck、Steam Deck OLED、ROG Ally、Leigon Go、 MSI Claw に対応。(ROG Ally X とは互換性がありません)
📢注意:
- ROG Ally の高性能 30W モードをより快適に体験するには、100W 充電器の使用をお勧めします。
-
本製品はAYA NEOコンソールには対応しておりません。また、ROG Allyの30Wターボモードの動作は、使用する充電器に依存するため保証できません。対応デバイスの詳細については、以下の製品仕様をご確認ください。
SPEC
Hardware Interface USB Type C, Ethernet, HDMI, USB 2.0
4.45 x 2.64 x 1.1 inches
USB-A 2.0*2、PD USB-C*1、HDMI 2.0*1、RJ45*1
Wattage: 100 watts
HDMI: 4K 60Hz / 2K 120Hz
PD(USB-C): PD 100W Max, Only supports PD USB-C interface input, compatible with PD2.0, 3.0
RJ45:100Mbps
USB-A: Support 480Mbps transmission, 5V/1A,
TPE+Aluminum
140g
Supports Steam Deck, Steam Deck OLED, ROG Ally, Legion Go, MSI Claw.
📢NOTE:
- NOT compatible with AYA NEO console. Cannot guarantee 30W Turbo Mode for ROG Ally. It may require a charger over 65W, based on current information. Ultimately, enabling 30W Turbo Mode depends on the specific charger used.
- NOT compatible with ROG Ally X, For optimal use, we recommend purchasing the HB0609.
It got 100 Mbps Ethernet & USB 2.0 instead of the Gigabit Ethernet & USB 3.0.
NOT compatible with Protective Case with Kickstand, Please ensure that the thickness of your protective case is less than 2mm.
When your Steam Deck is connected to Docking Station, you need to adjust its resolution after entering desktop mode in order to achieve 4K output.
Since many games themselves are not well adapted in handheld mode, you may not be able to adjust the 4K resolution if you enter the game from handheld mode. We recommend that you restart the game and open the game you want in desktop mode to complete the 4K output.
If you want to achieve 4K@60Hz output, be sure to use an HDMI 2.0 cable or higher standard version. Also, please use as few cable adapters as possible, as using too many cable adapters can cause signal degradation, resulting in the inability to output 4K signal.
When you are docking your steam deck and need to connect high power external devices, please make sure you connect your PD charge to the docking staion to ensure that you can power the high power external devices. (Steam Deck and Docking Station cannot power high power external devices by themselves).
Do not use HDMI to DisplayPort cables or adapters please.
When running big games, too high image can put a large burden on the Steam Deck, which may be not capable of handling such high power consumption.You can reduce the picture quality of the game appropriately to reduce the latency of the external device during the game.
If you need to use HDMI Switch (the 8K one is better), make sure that the HDMI cable at both ends of it does not exceed 6.6 Feet.
SHIPPING & RETURN
ご注文前に配送に関するヒントをよくお読みください。
- 50 ドル以上のご注文はすべて送料無料となります。
- 49.99 ドル未満の注文には送料として 6.99 ドルが請求されます。
(注:上記の配送ポリシーはFlipGoには適用されません。具体的な配送方法については、FlipGoの製品ページをご覧ください。)
ご注意ください:
- JSAUX GAMINGは、世界中のお客様に迅速かつ効率的な配送サービスを提供しています。(ただし、軍事施設(APO/FPO)および一部の島嶼部には商品を配送できません。)
- 現在、すべての注文の処理時間は 2 ~ 4 日かかります (週末は注文は処理されません)。
- ご注文のお届けには7〜12営業日かかります(先行販売商品は除く)。
- 国際関税および税金が適用される場合がありますが、チェックアウト時には計算されません。
- 先行販売商品の発送時期については商品ページの指示に従います。
物流サービスプロバイダーの要件により、
- ご注文をできるだけ早く準備し、配送の問題を回避するために、正確な番地や配送会社に必要なその他の情報を含む正確な住所を必ず入力してください。
-
中国本土および台湾のお客様:中国本土のお客様は、Tmall をご利用の上ご注文ください。香港、マカオのお客様は、氏名、身分証明書番号、配送先住所を繁体字中国語でご記入ください。
- サウジアラビアの場合: 50ドル以上のご注文で送料無料は適用されません。送料は14.99ドル(VAT込み)となります。
- 物流上の理由により、当社は次の国および地域への注文サービスを一時的に提供していません:アフガニスタン、アルバニア、アルジェリア、アンドラ、アンゴラ、アンギラ、アルゼンチン、アルメニア、アルバ、アゼルバイジャン、バーレーン、バングラデシュ、バルバドス、ベラルーシ、バミューダ、ブータン、ボスニア・ヘルツェゴビナ、ブラジル、英領ヴァージン諸島、ブルネイ、ブルキナファソ、ブルンジ、ボリビア、カンボジア、カメルーン、ケイマン諸島、中央アフリカ共和国、中国、クリスマス島、コスタリカ、コートジボワール、ジブチ、コンゴ - ブラザヴィル、コンゴ - キンシャサ、エジプト、エルサルバドル、エクアドル、フォークランド諸島、フェロー諸島、フランス領ポリネシア、ガボン、ガンビア、ジョージア、ガーナ、ジブラルタル、グリーンランド、グアドループ、グアテマラ、ガーンジー島、ギニア、ホンジュラス、アイスランド、インドネシア、イスラエル、ジャマイカ、ヨルダン、ジャージー、カザフスタン、ケニア、キリバス、キルギス、レバノン、レソト、リベリア、リヒテンシュタイン、モルディブ、モーリシャス、マルティニーク、モルドバ、モナコ、モンゴル、モンテネグロ、ミャンマー(ビルマ)、ナミビア、ナウル、ニューカレドニア、ニカラグア、ニジェール、ナイジェリア、ノーフォーク島、北マケドニア、ノルウェー、オマーン、パキスタン、パラグアイ、ルワンダ、サンマリノ、セネガル、セルビア、セイシェル、ソロモン諸島、南スーダン、スリランカ、スーダン、タジキスタン、トーゴ、トンガ、チュニジア、トルクメニスタン、ツバル、ウガンダ、ウクライナ、ウルグアイ、インド、ウズベキスタン、バヌアツ、バチカン市国、米国の一部の地域(含む)プエルトリコ、グアム、米領バージン諸島、北マリアナ諸島、アメリカ領サモア、および APO、FPO、DPO などの軍事基地。
15日間返品:
返品・交換ポリシーは、商品をお受け取りになった日から15日間有効です。詳しくは、配送ポリシーのセクションをご覧ください。
Comparison Of Different Version Docking Stations
5-in-1 Docking Station HB0602
7-in-1 RGB Cooling Docking Station HB0705
6-in-1 Multifunctional Docking Station HB0609
6-in-1 Docking Station HB0603
M.2 6-in-1 Docking Station HB0604
7-in-1 Docking Station HB0702
11-in-1 Docking Station HB1101
112*65*28mm
135g
138*145*143mm
360g
125*85*49mm
179g
140*65*28mm
150g
138*86*30mm
290g
150*67*28mm
150g
120*61.8*23.5mm
130g
TPE+Aluminum
Aluminum Alloy + ABS & PC
ABS+PC+TPE
TPE+Aluminum
TPE+Aluminum
TPE+Aluminum
Aluminum alloy+ABS&PC
USB-C *1
USB-C *1
USB-C *1
USB-C *1
USB-C *1
USB-C *1
USB-C *1
HDMI 2.0*1
4K@60Hz/ 2K@120Hz
HDMI 2.1 *1
4K@120Hz/ 1080P@240Hz
Gaming Features: VRR, ALLM, HDR, QFT
HDMI 2.1 *1
4K@120Hz/ 1080P@240Hz
HDMI 2.0 *1
4K@60Hz/ 2K@120Hz
HDMI 2.0 *1
4K@60Hz/ 2K@120Hz
HDMI 2.0 *1
4K@60Hz/ 2K@120Hz
HDMI 2.1 *1
4K@120Hz
✘
✘
✘
✘
✘
Display Port *1
4K@60Hz/ 2K@120Hz
Display Port *1
4K@120Hz
USB-A 2.0 *2
USB-A 3.0 *2
USB-C 3.0*1
RGB-powered USB-C*1
USB-A 3.0 *2
USB-C 3.0*1
USB-A 3.0 *3
USB-A 3.2 *3
USB-A 3.2 *3
USB-A 3.0 *2
USB-A 2.0 *1
Ethernet RJ45 100Mbps
Gigabit Ethernet (1000Mbps)
Gigabit Ethernet (1000Mbps)
Gigabit Ethernet (1000Mbps)
Gigabit Ethernet (1000Mbps)
Gigabit Ethernet (1000Mbps)
Gigabit Ethernet (1000Mbps)
✘
✘
✘
✘
✔
✘
✘
✘
✘
✘
✘
✘
✘
✔
✘
✘
✘
✘
✘
✘
✔
✘
✘
✘
✘
✘
✘
✔
Steam Deck/OLED
ROG Ally
Legion Go
Steam Deck/OLED
ROG Ally
ROG Ally X
Legion Go
Steam Deck/OLED
ROG Ally
ROG Ally X
Legion Go
Steam Deck/OLED
ROG Ally
Legion Go
Steam Deck/OLED
ROG Ally
Legion Go
Steam Deck/OLED
ROG Ally
Legion Go
Steam Deck/OLED
ROG Ally
Legion Go
Switch
Samsung Monitor LG32G73TQSNXZA
65” Sony Bravia K65XR80
Samsung UE50NU7400U 50" 4K Ultra HD Smart
LG UM7180PVB
Samsung Monitor LG32G73TQSNXZA
65” Sony Bravia K65XR80
Samsung UE50NU7400U 50" 4K Ultra HD Smart
LG UM7180PVB
Samsung Monitor LG32G73TQSNXZA
65” Sony Bravia K65XR80
Samsung UE50NU7400U 50" 4K Ultra HD Smart
LG UM7180PVB
Samsung Monitor LG32G73TQSNXZA
65” Sony Bravia K65XR80
Samsung UE50NU7400U 50" 4K Ultra HD Smart
LG UM7180PVB
Samsung Monitor LG32G73TQSNXZA
65” Sony Bravia K65XR80
Samsung UE50NU7400U 50" 4K Ultra HD Smart
LG UM7180PVB
Samsung Monitor LG32G73TQSNXZA
65” Sony Bravia K65XR80
Samsung UE50NU7400U 50" 4K Ultra HD Smart
LG UM7180PVB
Samsung Monitor LG32G73TQSNXZA
65” Sony Bravia K65XR80
Samsung UE50NU7400U 50" 4K Ultra HD Smart
LG UM7180PVB
FAQ
Q1. Why do SD cards become inoperable or unwritable?
A1. SD card format is not compatible with the Steam Deck system, you need to back up the SD card in advance and then format it to the correct format.
Q2. Does the docking station output video over a USB-C port?
A2. No, the USB-C port is for power input only.
Q3. Why does the flicker occasionally appear after I connect the Steam Deck to the monitor via Docking Station HB0602 for a period of time?
A3.After a long gaming experience, Steam Deck will enter a self-protection mechanism due to overheating. At this time, the occasional screen flicker is a mechanism of reducing the frequency of the screen, which is a normal phenomenon.
Q4. Some instructions for customers when setting resolution in desktop mode.
A4. 1. You can modify the resolution in desktop mode or game mode (Steam Deck version 3.3.2 and above)
2. It is recommended that after connecting the monitor, only the monitor should be used as the main playing screen, both "Enabled" and "Primary" under "Laptop Screen" should be unchecked.
This will provide a better gaming experience and also reduce the power consumption of the console screen.
3. If you need a split screen experience, we also recommend separating the two screens, otherwise, there will be a screen overlap situation.
(At present, due to Steamdeck system bug, so there is no way to split the screen to put the icons of two screens on one screen)
Q5. How to turn on the ROG Ally 30W turbo mode with JSAUX Dock?
A5. It is recommended to use a PD 100W charger to better experience ROG Ally’s high-performance 30W mode.
If you're using a multi-port 100W charger, please avoid connecting other devices at the same time. This helps ensure stable power delivery and optimal performance for the docking station and your device.
