スチームデッキ用透明バックプレート

A1.After installing the button, first, check whether there is a gap between the button and the buckle and whether it can be pressed and rebounded normally.
If there is a gap that can be pressed and rebounded normally, continue to install.
If there are no gaps, proceed as follows:
1) Loosen the button screw for 2-3 turns. This method can make the space inside the button bigger, but it will make the whole button feel loose.
2) Add a gasket of M3 or M4 size to the yellow nut (the size of the gasket is about 5-6mm in outer diameter, 3.2mm in inner diameter, and 0.5mm in thickness. You can also trim a gasket with harder cardboard according to this size) , this method increases the pressing space at the other end by raising the nut.
3) Slightly loosen the back cover screws near the stuck button for 2-3 turns. For example, if R4 will be stuck, loosen the three screws closest to R4. This method can increase the pressing space, please be careful not to screw it too loosely.

2. Check if there is a gap at the top, because the gap is caused by deformation, and deformation may also cause the button to get stuck.
If there is no gap, continue with the installation. If there is a gap, remove the thermal grease and reinstall it.

A2. The transparent case is the same size as the original back cover. If you choose a lower or medium button , it is compatible with all JSAUX protective cases.

A3. That is normal, the thermal grease conducts heat from the Steam Deck circuit board. In addition, because the aluminum itself has good thermal conductivity, it will be hotter than other areas when touched, so be careful not to touch it to avoid being burned.
If you still feel too hot, you can also remove the inner thermal grease.

A4. It will not affect the original heat dissipation of the Steam Deck. Because the air inlet and outlet of the steam deck heat dissipation are separate heat dissipation pipes, and the thermal grease will not block the heat dissipation channels.

A5. It cannot be put into the original valve carrying case and JSAUX-BG0102 carrying case, but it can be put into JSAUX shoulder bag-BG0105 or carrying case-BG0106.

A6. Actual colors may vary. This is due to computer monitors & screens displaying colors differently and everyone can see these colors differently.

A7. The transparent back plate PC0106 is incompatible with OLED.
